Setting Up AccountLinx for Maxwell Systems StreetSmarts

With AccountLinx, you can export your employees' time data from ExakTime Connect into a compatible file for Maxwell Systems StreetSmarts. As Maxwell was acquired by Viewpoint and discontinued StreetSmarts, this resource is kept for reference for anyone still using StreetSmarts, but this does not guarantee that AccountLinx will continue to work with American Contractor in the future.

If you have any questions or concerns during setup and/or use, you can contact us with the "Request Support" link at the top of the page and we will try to assist as best as possible. Keep in mind, however, that we are not Maxwell support. We will try to help you as much as we can, but there are aspects of Maxwell that are out of our area of expertise.

Selecting Maxwell as your Exporter

  1. Go to Tools and click Exporter Settings...
  2. The Exporter Settings window should open. Click Select Exporter...
  3. A window with a list of available exporters should open. Select "Maxwell StreetSmarts" and click OK.

AccountLinx Setting Unique to Maxwell

The Maxwell export for AccountLinx offers a variety of settings when exporting your time data to help tailor the time data to your company's needs. These settings are unique to AccountLinx and will not affect ExakTime Connect or Mobile. If the settings offered do not sound familiar, you may not be using the setting in Maxwell and can leave it as <None>.

  1. Go to Tools and click Exporter Settings...
  2. The Exporter Settings window should open. Click Configure....
    • Default Earn Codes
      • Regular Earn Code - Enter the regular earning code as used in Maxwell.
      • Overtime Earn Code - Enter the overtime earning code as used in Maxwell.
      • Doubletime Earn Code - Enter the doubletime earning code as used in Maxwell.
    • Use Alternative Earn Codes
      • Map Earn Codes to - Specify if an alternate earn code should be associated with specific employees, locations, or cost codes. This allows particular employees, locations, or cost codes to have an alternate set of earn codes when exported. The related mapping screen will show fields to enter the earn code that should be associated with exported time records. If an entity does not have an alternate earn code, it will use the default earn code instead.
    • Optional Settings
      • Map Job Class to - Specify which entity the job class should be associated with. The related mapping screen will have additional fields for you to complete.
      • Map Unit Rate to - Specify which entity the unit rate should be associated with. The related mapping screen will have additional fields for you to complete.
      • Map Union Code to - Specify which entity the union code should be associated with. The related mapping screen will have additional fields for you to complete.
      • Map Plant to - Specify which entity the plant should be associated with. The related mapping screen will have additional fields for you to complete.
      • Map COP Code to - Specify which entity the COP code should be associated with. The related mapping screen will have additional fields for you to complete.
    • Comments/Notes Export
      • Specify if employee, location, cost code, or time record comments should be included with your time data export.
  3. Click OK on the Configuration window and click OK on the Exporter Settings window to return to the main page of AccountLinx.
  4. Click the appropriate "Map Employee/Location/Cost Code" option to see the columns from the options enabled in Step 3.

General Use of AccountLinx

After setting up the configuration of AccountLinx to better match Maxwell in the previous section, you will need to:

  • Map your entities so any time data associated with an ExakTime entity will match with an Maxwell entity and fill in any relevant fields enabled in the previous section. Refer to the following article if you are unfamiliar with mapping your data in AccountLinx.
  • After mapping your entities, you can export your time data to import into Maxwell. Refer to the following article if you are unfamiliar with exporting time data from AccountLinx.

Example of AccountLinx Export

An example of an AccountLinx export has been provided below. The data have been preformatted based on Maxwell's template. The presented values can differ depending on your settings.

ALX - Export Errors - Maxwell StreetSmarts - 00.png

While you can manipulate the exported data after it has been exported, it is highly discouraged as it can result in data discrepancies when double-checking any data.
